Dust Filter
♦
Secondary Filter
♦
Activated Carbon Filter
♦
UV Filter
♦
Negative Ion Generator
♦
Hepa Filter
♦
Electrostatic Precipitator
♦
Ozonation System
UV Sterilizer-Ozain Air
Sterilization system device for airborne disinfection in medical environment, Hospitals, Surgeries, Dental, offices and diagnosis rooms.
Stage-I Dust filter traps particles upto 15 microns. This includes dust particles, hair, lint fibers, insects and other particulate substance above 15 micron.
Stage-II Secondary filter traps particles up to 5 micron size such as fine dust particles, pollen grains, etc.
Stage-III Activated carbon filter removes odors, fumes, inorganic substances such as No and CO and organic compounds such as formaldehyde and fumes of halogens and other chemicals. 2
Activated Carbon absorbs particles from air.
Stage-IV U V rays (2537A or 253.7nm) kill microbial cells present in the air by destroying their genetic material with an efficiency of 90-99%.
Stage-V A Digital Negative lons Generator is another excellent feature which ultimately leads to better air quality. Negative lons get attached to dust particles / pollutants making them heavier
and precipitate them on the floor. This leads to cleaner air.
State-VI Hepa Filter traps all biotic and abiotic particles known to be present in the air. 0.3 micron porosity of the filter results in 99.97% efficiency. Only pure air passes through this porosity.
State-VII Electrostatic precipitator, a wonderful feature, high D.C. Current attracts & retains all the pollutants of air that pass through it.
State-VIII Ozonation system with a programmable digital time: Ozone sterilizes air by oxidation of inorganic and organic substances. 99.9% of bio contaminants are killed and eliminated by
Ozone.
When the system is producing Ozone (Stage-VII)) the Stages-IV, V, & VI are automatically switched off and vice-versa
Technical Specifications
Dimensions : 29” x 21” x 10”
Gross Weight : 22 kg (Approx)
Voltage Required : 230V AC, 50 Hz
Area Recommended : up to 4000 Cubic feet
Digital Timers : Two (for mains and Ozone)
